Product Description:
Size: Varies Depending On The Type And Purpose Of The Dredger
Power Source: Diesel Engine Or Electric Power
Maintenance: Regular Maintenance And Inspection Required For
Optimal Performance
Cutter Type: Rotating Cutter Head
Introducing our 1500m3/h mud dredger equipment, the perfect
solution for efficiently removing mud and debris from marine
environments. Our dredger equipment is designed to be durable and
reliable, able to withstand the harsh conditions of marine dredging
operations.
The size of our dredger equipment varies depending on the type and
purpose of the dredger, but all models feature a rotating cutter
head to effectively break up and remove sediment. The power source
can be either a diesel engine or electric power, giving operators
the flexibility to choose what works best for their specific needs.
Regular maintenance and inspection is necessary to ensure optimal
performance and prolong the life of the dredger equipment. Our team
of experts is available to provide maintenance and repair services
as needed, keeping your equipment running smoothly.
Invest in our 1500m3/h mud dredger equipment for a reliable and
efficient solution to your marine dredging needs.
Features:
- Product Name: Dredger Equipment
- Mobility: Self-propelled Or Towed By A Tugboat
- Size: Varies Depending On The Type And Purpose Of The Dredger
- Environmental Impact: No Cause Disturbance To Marine Ecosystems
- Type: Marine Dredging Equipment
- Function: Excavation And Removal Of Mud Or Debris From The Bottom
Of Water
Floating dredger equipment in China, floating dredger equipment in
China, floating dredger equipment in China.
Special requirement for cutter suction dredger can be custom
building
| Standard Model list for hydraulic cutter suction dredger |
| Model | Inch | Diameter pipe | Water flow | Solid capacity | Total power | Dredging depth | Discharge distance |
| YSCSD150 | 6 Inch | 150 mm | 260 m3/h | 30 cbm/h | 102 KW | 4 m | 600 m |
| YSCSD200 | 8 Inch | 200 mm | 600 m3/h | 80 cbm/h | 213 KW | 6 m | 800 m |
| YSCSD250 | 10 inch | 250 mm | 1,000 m3/h | 160 cbm/h | 367 KW | 8 m | 1,100 m |
| YSCSD300 | 12 inch | 300 mm | 1,500 m3/h | 240 cbm/h | 591 KW | 10 m | 1,100 m |
| YSCSD350 | 14 inch | 350 mm | 2,400 m3/h | 360 cbm/h | 971 KW | 12 m | 1,200 m |
| YSCSD400 | 16 Inch | 400 mm | 3,000 m3/h | 500 cbm/h | 1,057 KW | 14 m | 1,400 m |
| YSCSD450 | 18 Inch | 450 mm | 3,500 m3/h | 700 cbm/h | 1,462 KW | 15 m | 1,500 m |
| YSCSD500 | 20 Inch | 500 mm | 3,800 m3/h | 760 cbm/h | 1,648 KW | 15 m | 1,600m |
| YSCSD600 | 24 Inch | 600 mm | 6,000 m3/h | 900 cbm/h | 2,511 KW | 15 m | 1,800 m |
| YSCSD650 | 26 Inch | 650 mm | 7,000 m3/h | 1,400 cbm/h | 3,705 KW | Max.18m | 1,800m
|
Applications:
The YSCSD300 model has a suction pipe diameter that varies
depending on the type and purpose of the dredger. It can be used
for small-scale dredging operations or for larger dredging
projects. This cutter suction dredger equipment is designed to
efficiently remove sand, mud, and other materials from the seabed.
The 18 inch hydraulic dredger machine is powered by either a diesel
engine or electric power, depending on the preference and
availability of the operator.
There are several application occasions and scenarios where the
Yongsheng dredger equipment is highly useful. It can be used for
coastal protection and beach nourishment projects, land
reclamation, and the construction of ports and harbors. The dredger
equipment is also useful in environmental remediation projects,
such as the cleanup of polluted rivers and lakes.
The Yongsheng dredger equipment is also highly useful in mining
operations, particularly in the extraction of minerals from the
seabed. The dredger equipment can be used for the excavation of
sand, gravel, and other minerals that are used in the construction
industry. It is also useful in the oil and gas industry,
particularly in the construction of offshore oil rigs and
pipelines.
The size of the Yongsheng dredger equipment varies depending on the
type and purpose of the dredger. The product is available in
different sizes to cater to the specific needs of the operator.
This versatility makes it highly useful in various water
applications, from small-scale dredging operations to large-scale
construction projects.
